CANON K30291 AC DC POWER SUPPLY 24V 1.2A FOR CANON PIXIMA MP310 PHOTO PRINTER SCANNER K10303




€¢ Condition: New - Excellent - Working - Pulled
€¢ Content: One  Power Supply  only

Please Note: Its Original
Manufacturer/Brand: Canon / Delta Electronics
Model / SKU: K30291
Compatible Model No.: K30292
P/N.: QK1-3922-DB01-01
Compatible P/N.: QK1-3720-DB01-01 , 1588-2500 , HU10104-7160, NSW22475, NSW22476 ,  1588-2500, HU10104-7160 , QK1-3922-DB01-01 , NSW22475

 Input Voltage: 100-240V 50/60Hz  0.7A
[ ■ ■ ■ ] Output: 24V === 1.25A
Output: 24V DC
Amperes / Watts:   1.2A
Connector: 3 pin rectangle white flat 1 [ ■ ■ ■ ] 3
(from Left to right)
Pin1 - 24v
Pin2 - Cont
Pin3 - GND
Connector size Pin Dimension : OD 10 x 4 mm   (aprox.)    [ ■ ■ ■ ]

Dimension 13.5 x 7 x 4 cm (L x W x H)
(Not including protruding parts)
Weight 150g

To Use With:
Canon Pixima MX310 , MP310, MP210, MP470 All in one Scanner Photo Printer, K10303 , K10308, K10306, QC2-516-DB02-02, QC2-516-DB03-01
Canon Pixima MP210, MP470 All in one Scanner Photo Printer, K10308, K10306, QC2-516-DB02-02, QC2-516-DB03-01

Special Note :
€¢ Some times Part no.   Model no. or serial no. may or may not same but product will be compatible.
€¢ It's important to buy the correct Power Supply for your device.   No Matter you're replacing a defective or lost power supply or simply purchasing one to go with a product that needs power, Full range input, Single output)
