EPSON EPS-122 AQ C361A C363A INTERNAL POWER SUPPLY 120V 0.5A   PSU FOR EPSON STYLUS CX9400 Workforce 500 600 Scanner FAX ALL IN ONE PRINTER

Condition: New - Works
Content: One  Power Supply  only

Manufacturer: EPSON
Model Number: EPS-122 AQ , C696 PSB    , C363A or C361A
Part Number: JK88J08KE/1468088-04 , JK88J08KE 1468088-04 , JK88187A , KPC2294V-0
ASSY.: 2116757 02

Input Voltage: 120VAC ~ 0.5A 50-60Hz
Output Voltage: 42VDC approx. (masure by Multimeter may not accurate)
Connector: Flat 3 Pin Gray
Pin1 (Blue) = 42V DC
Pin2 = GND
Pin3= 42VDC
Connector size: OD  6.5 x  3.5 mm [ ■ ■ ■ ]

Dimension: 15.5 x 10.5 x 4.5 cm approx.
Weight: 350 grams.

Additional Information: To use with Epson Stylus CX9400 , Work force 500, 600 FAX ALL-IN-ONE PRINTER
