UMEC UP0451E-15P AC Adapter 15VDC 3A LIKE NEW -( )- 2x5.5mm ROUND BARREL 100-240VAC 45W Power Supply Backword compatible for generic use and laptops


Manufacturer UMEC
Model UP0451E-15P , UP 0451E-15P
P/N.: 3882A004 , 097-020131-735
Compatible with: TEAD-66-153000U

 AC Input: 100-240V and 47-63Hz
DC Output: 15VDC 3.0A - ---C---
Connector / Plug: Coxial Round Barrel
■ Pin Dimensions: 2.1 x 5.5 x 10 mm approx.
A Inner diameter - 2.1mm
B Outer diameter - 5.5mm
C Length - 10 mm

INPUT SPECIFICATIONS
Input Voltage Range €¦ €¦ €¦ €¦ €¦ €¦. €¦ €¦ €¦ 90-264VAC
Input Frequency €¦ €¦ €¦ €¦ €¦ €¦ €¦ €¦ €¦. €¦ €¦ €¦ 47-63 Hz
Inrush Current €¦ €¦ €¦ €¦.... €¦ €¦ €¦ 40A max.(Cold Start)
GENERAL SPECIFICATIONS
Hold-up Time €¦ €¦ €¦ €¦ €¦ €¦ €¦ €¦. €¦ €¦. €¦ €¦ 10mS typ.
Leakage Current €¦ €¦ €¦ €¦ €¦ €¦ €¦ €¦. €¦... €¦.0.5mA max.
Short Circuit Protection €¦ €¦ €¦ €¦ €¦ €¦ €¦ €¦. Continuous
Overvoltage Protection €¦ €¦ €¦ €¦ €¦ €¦ €¦ €¦ €¦.. Optional.
Continuous Output Power . €¦ €¦ €¦ €¦ €¦. €¦ €¦ 45W max.
Hi-pot Isolation: Input / Output €¦ €¦ €¦ €¦ €¦ €¦4242 VDC
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature Range €¦ €¦ €¦ €¦ €¦. 0 °C to 50 °C
Derating 50 °C to 70 °C €¦ €¦ €¦ €¦ €¦ €¦.. €¦ €¦ €¦      2%/ °C
Temperature Coefficient €¦ €¦ €¦ €¦ €¦ €¦ €¦ ± 0.02%/ °C
Storage Temperature Range €¦ €¦ €¦.. €¦. €“40 °C to 85 °C
Humidity, Non-Condensing €¦ €¦ €¦ €¦ €¦ €¦ 0 to 95% RH
Cooling €¦ €¦ €¦ €¦ €¦ €¦ €¦ €¦ €¦ €¦.Free- Air Convection
EMI Filter (on Board):
Conducted €¦ €¦ €¦.... €¦. Meets FCC/CISPR 22 Class B
Weight: 300g
Case Material: ABS Plastic UL94V-0 Flammability Rated
IN 2.5/ OUT5.5 DC PLUG FEMALES
 Info

To use with:
Hub, Router, Modem
AZS#4894 - CAMBRIDGE SOUNDWORKS TEAD-66-153000U PlayDock MP3 player 2.1 x 5.5 x 12 mm
iHome iH6 iPod station speaker system not sure may need pin converter from 2.1 to 2.5mm

Information's are here for your reference only and accuracy can not be guaranteed.
