ZVC60NT15E AC DC ADAPTER 15V 4A 60W POWER SUPPLY

CONDITION: New - Works
CONTENT: ONE Adapter ONLY

Possible Manufacturer: Snaptec Power Conversion Products
Model: ZVC60NT15E
Part Numbers:   60NT15E Rev B

 INPUT: 100-240V ~ 70-90VA 50-60Hz
input Standard: International IEC320, C8 type two pin
 OUTPUT: 15V=== 4A 60W
Connector: round barrel - ----C----
Pin / DC Plug Dimension: 2.5 x 5.5 x 10 mm approx.  (AxBxC)
A Inner diameter - 2.5mm
B Outer diameter - 5.5mm
C Length - 10 mm

Output Standard:
Centre positive.
 Right angle hollow co-axial plug Size,
2.54mm ID, 5.49mm OD, 9.6mm length.
Cord length: 1 meter

OPERATING TEMP: 0 °C to 40 °C at rated power. Derate 2.5% per °C from 40-70 °C
RIPPLE & NOISE: 250 - 500mV model dependent
MINIMUM LOAD: No minimum load required for operation, but a minimum load of 10% is required to meet regulation specifications.

Dimension: 11.3 x 6 x 3cm approx.
Weight: 220 grams.   approx.

Features
€¢ Universal input 90~264VAC.
€¢ High power density, 8 watts per cubic inch
€¢ Ultra miniature package
€¢ Light weight
€¢ Meets international EMC standards
€¢ CE marked and EMC approved
€¢ Meets international safety standards IEC950, EN60950, UL1950, AS609050
€¢ Field proven design topology
€¢ Quality components, high MTBF >100,000 hrs
€¢ OVP and overload protection
€¢ Convection cooled

Compatible with / Applications:
€¢ Point of sale equipment
€¢ Computer peripherals
€¢ Touch screen displays
€¢ Date networking equipment
€¢ Telecommunications
€¢ Industrial control
€¢ Medical equipment

More info

Some times Part no.   Model no. or serial no. may or may not same but product will be compatible.
